High hardness & wear resistance (3000–5000 HV) – Ideal for machining hardened materials with HRC 45+
Excellent thermal stability (withstands temperatures over 1200°C)
High-precision machining capability: Enables mirror-like surface finish (Ra < 0.4 μm)
Versatile product range: Available in various sizes and thicknesses to meet diverse application needs
| Order no. | Outer diameter (mm) | Usable Diameter (mm) | PCBN Layer Thickness (mm) | Total Thickness (±0.05 mm) | CBN Content (%) | Grain Size (μm) | Application |
| SJC95 | 71 | 70 | 0.6-0.9 | 1.6-3.2 | 95% | 4 | High wear-resistant machining – Especially suitable for finishing applications in powder metallurgy and cast iron, as well as heavy interrupted cutting of hardened steel. |
| SJC95S | 71 | 70 | 0.6-0.9 | 95% | 0.8 | Ultra-precision finishing – Ideal for powder metallurgy and hard cast iron materials. | |
| SJC80 | 71 | 70 | 0.6-0.9 | 83% | 2 | Versatile performance – Applied to ferrous powder metallurgy, hard cast iron, and gray cast iron, along with medium-to-heavy interrupted cutting of hardened steel. | |
| SJC65 | 71 | 70 | 0.6-0.9 | 65% | 4 | Interrupted turning – Suitable for micro-to-medium interrupted turning of hardened steel and ductile cast iron. | |
| SJC60 | 71 | 70 | 0.6-0.9 | 60% | 2 | Stable turning – Designed for continuous-to-micro interrupted turning of hardened steel. | |
| SJC50 | 71 | 70 | 0.6-0.9 | 50% | 1 | Continuous cutting – Optimized for stable, continuous machining of hardened steel. |
